How to set up the Volume by Price study in Sierra Chart
To set up Volume by Price in Sierra Chart, add the Volume by Price study from Analysis >> Studies, set Volume Graph Period Type to Multiple Profiles Based on Fixed Time with a length of 1 Day for daily profiles, and set Ticks Per Volume Bar. The session times in Chart Settings decide what one day contains, and the display inputs decide whether you can read the profile at a glance.
The rest of this guide walks through each setting in order, with starting values for ES, NQ and CL, then covers session profiles, manually drawn profiles and troubleshooting. If you want the concept behind the most important level the study draws, read what point of control means in volume profile.
Get professional chartbooks for Sierra Chart
DOM, footprint, heatmap and market profile setups, installed in seconds. Our trading courses cover the method behind them.
“Chartbooks are superb, I save a lot of time! Thanks for these quality products.”
Before you add the study: check the chart data
Volume by Price can only be as accurate as the data underneath it. Three checks are worth doing first.
- Intraday data storage. Go to Global Settings >> Data/Trade Service Settings and confirm that Intraday Data Storage Time Unit is set to 1 Tick. Sierra Chart's documentation asks for 1 Tick or 1 Second records for good accuracy. With coarser records, volume inside each record is spread evenly across its price range, so price-level detail is approximated rather than exact.
- Tick Size. In Chart >> Chart Settings, confirm the Tick Size matches the contract, for example 0.25 for ES. Too small slows loading, too large makes profiles inaccurate.
- Enough history loaded. In the same window, check Days to Load. A weekly profile on a chart that only loads three days will be incomplete without any warning.
Use a futures contract with real exchange volume, such as ES, NQ or CL from CME Group. Spot forex pairs like EURUSD only report tick counts from your feed, not centralized volume, so a profile built on them shows activity on that feed rather than market-wide volume. If you study the euro, the 6E futures contract is the closer equivalent.
Step 1: add Volume by Price to the chart
- Open the chart and go to Analysis >> Studies.
- In Studies Available, find Volume by Price and click Add.
- Select it in Studies to Graph and click Settings, then open the Settings and Inputs tab.
Sierra Chart documents every input on its Volume by Price study page. You can add the study more than once to the same chart, which is how you show a daily and a weekly profile together.
Step 2: choose the profile period
The profile period is the setting that changes the meaning of the study the most. Sierra Chart calls Volume Graph Period Type the most important input. The common choices behave like this:
| Volume Graph Period Type | What it draws | Use it for |
|---|---|---|
| Multiple Profiles Based on Fixed Time | One profile per period across the chart, starting at the session Start Time | Daily or weekly session profiles on ES or NQ |
| Visible Bars | One profile from whatever is on screen, recalculated as you scroll or zoom | Ad hoc analysis; the levels move |
| All Bars in Chart | A single profile across all loaded data | Composite context; depends on Days to Load |
| Multiple Profiles Based on Bar Count | A new profile every N bars | One profile per bar, or per group of bars |
| One Period at End of Fixed Time Length | One rolling profile covering the last fixed length, for example 1 day back from the last bar | Recent activity only |
| From Session Start Time to End | One profile for the current trading day | A single live session profile |
With Multiple Profiles Based on Fixed Time, set Time Period Type for 'Fixed Time' to Days and Time Period Length for 'Fixed Time' to 1 for daily profiles. Change the type to Weeks for weekly profiles.
If the chart also has the TPO Profile Chart study, the period type is set to Based on TPO Chart automatically. To choose another period, set Set as Independent Volume Profile for TPO Chart to Yes.
Match the period to the session
For index futures, decide whether a "day" means the full Globex session or the regular trading hours. Daily profiles use the session times set in Chart >> Chart Settings. If you want RTH-only profiles for ES, set the session to 09:30 to 15:59:59 Eastern rather than trying to fix it inside the study. Overnight volume in ES is often thinner, so including or excluding it can move the point of control and value area noticeably. The session section below covers this in detail.
Step 3: set ticks per volume bar
Ticks Per Volume Bar controls how many price ticks are grouped into one row of the profile. The default is 2, and Sierra Chart recommends 1 or 2 on intraday charts, with 1 for maximum detail. Too small and a weekly profile can become a smear of hairline rows. Too large and you hide the shape you are trying to read.
Practical starting points, which you should adjust to your screen and zoom:
| Instrument | Tick size | Daily profile | Weekly profile |
|---|---|---|---|
| ES | 0.25 | 1 tick | 2 to 4 ticks |
| NQ | 0.25 | 2 to 4 ticks | 8 to 16 ticks |
| CL | 0.01 | 2 to 5 ticks | 10 or more ticks |
NQ moves through far more ticks per day than ES, which is why it usually needs a larger row size for the same visual density. Grouping rows changes where the POC is reported, because volume is summed across the grouped ticks. If exact POC and value area prices matter more than looks, use 1. Either way, keep the row size consistent when you compare one day to another.
Step 4: pick the volume type to display
Volume Bar Calculation Method decides what sets the length of each row:
- Total Volume. One bar per row. Cleanest for reading value area and high and low volume nodes.
- Bid Volume or Ask Volume. Row length from one side only.
- Ask Volume - Bid Volume. Row length from the absolute difference, which shows imbalance per row rather than size.
To color each total-volume row by its bid and ask parts, use Bid Volume and Ask Volume Coloring Method instead. For most traders, total volume on the main profile is the readable default. If you want aggressor detail at every price inside each bar, that is the job of a footprint, not a profile. The Sierra Chart footprint chart setup guide covers that side.
Step 5: choose the display style and placement
Display settings decide whether the profile helps or covers your price bars.
- Right Align Volume Bars. Draws each profile on the right side of its period. For a single profile, also set Align to Far Right to Yes to place it beside the price scale. With multiple profiles, Always Display Last Profile Within View keeps the current one visible.
- Maximum Volume Bar Width Type and Percentage. The type bases the longest row on the Period Length, the Window Width, or Automatic. The percentage sets how much of that space it uses. Start around 25 to 35 percent of the period for daily profiles so candles stay visible underneath.
- Use Transparent Draw Style and Transparency Level. Higher levels are more transparent. Sierra Chart notes that transparency raises CPU use, so set up the profile without it first and add it last.
- Colors. On the Subgraphs tab, use one neutral color for normal rows, a distinct color for value area rows, and a highlight for the POC row.
On a 5-minute ES chart, a right-aligned daily profile at about 30 percent width with mild transparency tends to stay legible without crowding the bars. Test it on your own monitor before locking it in.
Step 6: configure value area and reference lines
In the same inputs you will find Value Area Percentage, normally 70 percent, and the options that mark the POC and the value area.
- Set Highlight Point of Control and Highlight Value Area to Yes to color those rows.
- Use Extend Point of Control and Extend Value Area to draw them as lines. The options are None, End of Period, End of Window and Until Future Intersection.
- Until Future Intersection keeps each prior level on the chart until a later profile trades through that price, which avoids a chart full of stale lines.
- For a developing POC that moves through the session, set Calculate Developing POC and Value Area to Yes and choose a Draw Mode that includes the POC, VAH, VAL lines.
The 70 percent figure is a convention inherited from market profile practice, not a rule. Changing it changes the levels, so use the same value across instruments if you compare them. If a TPO study is on the same chart, this percentage follows the TPO study's Volume Value Area % input, so change it there.
If you want Sierra Chart to flag price levels where volume crosses a threshold, rather than reading the profile by eye, see volume at price threshold alerts.
Step 7: save the configuration
Once the study reads the way you want, save it so you do not rebuild it on every chart. In Analysis >> Studies, type a name in the Save Studies As Study Collection box and press Save All, or save the whole chartbook with File >> Save. A study collection stores only the studies; a chartbook stores the full workspace. The difference is explained in Sierra Chart study collection vs chartbook.
If you would rather start from a configured workspace that already combines TPO, value area, POC and a volume profile, a Sierra Chart market profile chartbook gives you that layout to inspect and adjust.
Session times: full session vs day session profiles
With a profile period of one day, the session times decide what "one day" contains. They live in the chart settings, not in the study.
A session profile is a histogram of volume traded at each price between two timestamps. Move either timestamp and you change the input data, so the shape, the high volume nodes and the POC can all move.
Full session vs day session on ES
CME lists the E-mini S&P 500 (ES) as trading nearly around the clock, Sunday to Friday, from 6:00 pm to 5:00 pm Eastern Time with a daily maintenance break. You can confirm current hours for any contract on the CME Group trading hours page. Many index traders also watch the period that matches US cash equity hours, 9:30 am to 4:00 pm ET.
That gives you two reasonable definitions of an ES session:
- Full session: overnight Globex activity plus the day session, roughly 23 hours of trades.
- Day session (RTH): only the cash hours window.
The overnight session often trades lighter volume across a different price range. If it is included, the profile can show nodes from the overnight range that are absent from an RTH-only profile. Neither choice is wrong, but mixing them across charts produces levels that do not match.
What moves when the boundary moves
- Point of Control: the price with the highest volume can shift if overnight volume concentrated at a different level. See what is point of control in volume profile for the definition.
- Value area high and low: they are computed from the total session volume, so adding or removing hours changes them.
- Profile high and low: an overnight high outside the day range extends the profile.
- Prior day references: if you carry yesterday's POC or value area forward, the meaning of "yesterday" depends on the session definition.
Setting up an ES day session profile step by step
- Open Global Settings >> Time Zone and confirm the time zone. Session times are entered relative to it. This example assumes New York time.
- Open the ES chart, then Chart >> Chart Settings and find Session Times.
- Set Start Time to 09:30:00 and End Time to 15:59:59. Sierra Chart includes the full last second of the End Time, so 15:59:59 stops before the 4:00 pm bar. Check whether your intended close is 4:00 pm or 4:15 pm, because some traders include the extra index futures minutes.
- Leave Use Evening Session unchecked for RTH only.
- Apply the settings and let the chart reload.
- Add or open Volume by Price and set the profile period to one profile per day.
- Check the first and last bar of a recent session. The first bar should start at 9:30 and the profile should not include prints from the prior evening. For a single full-session ES profile, use reversed session times instead: Start Time 18:00:00 and End Time 16:59:59. When the start is later than the end, Sierra Chart treats the trading day as beginning the prior evening. Then confirm that each profile begins at the Globex open.
Separate overnight and day profiles
To get two profiles per date, one for the overnight session and one for the day session:
- In Chart Settings, keep Start Time and End Time on the day session, enable Use Evening Session, and set Evening Start and Evening End to the overnight hours.
- In the study, use Multiple Profiles Based on Fixed Time with a length of 1 Day.
- Set Use Separate Profile for Evening Session to Yes.
- On the Subgraphs tab, give the evening profile its own color with Evening Session Volume Bars Outline and Fill Colors.
Common session mismatches and how to spot them
- Two ES charts show different POCs for the same day: compare session times and the evening session option first.
- The Monday profile looks too large: Sunday evening activity may be included in Monday, which is expected on a full-session chart and a sign of misconfiguration on an RTH chart.
- Levels shift by one hour in March or November: the time zone probably does not follow US daylight saving rules.
- The profile and a TPO chart disagree on the session: TPO periods have their own settings, covered in Sierra Chart TPO profile chart setup.
Draw a fixed range profile with the Draw Volume Profile tool
Repeating session profiles come from the study. When you want one profile over a specific stretch, such as a balance area or a multi-day range, use Tools >> Draw Volume Profile. Click at the bar where the profile should start, then click where it should end. Sierra Chart inserts a Volume by Price study covering exactly that date-time range, and you can move either end later.
You choose the start and end time, not the price range, which comes from the bars inside it. And the tool does not work on TPO Profile Charts. For when to use a session profile and when to use a drawn range, see session volume profile vs fixed range profile.
Quick troubleshooting checklist
- Profile looks flat or blocky: row size too large for the instrument, or data stored above 1 tick.
- Weekly profile missing early days: Days to Load is too low.
- Levels move as you scroll: the period type is set to Visible Bars.
- Period type keeps reverting to Based on TPO Chart: the chart has a TPO study. Set Set as Independent Volume Profile for TPO Chart to Yes.
- POC differs from another chart or platform: check time zone, session times, Tick Size, row size and whether overnight volume is included. For an exact match, Sierra Chart also requires time-based bars on both charts, the same first and last bar time, and a Volume at Price Multiplier of 1 on intraday charts. Platforms like TradingView's volume profile use their own defaults, so identical numbers are not guaranteed.
Conclusion
A readable Volume by Price setup comes down to four decisions: which bars feed the profile, how many ticks make a row, which volume type is drawn, and where and how wide it sits on the chart. Get the data and session times right first, then tune row size per instrument and keep it consistent so profiles stay comparable. For ready-made Sierra Chart workspaces you can open and study, see the chartbooks at SierraOnShop.
FAQ
Can I show a daily and a weekly profile on the same chart?
Yes. Add the Volume by Price study twice, set one to a 1 day period and the other to 1 week, and give them different widths, colors and transparency so they do not hide each other.
Does Volume by Price work on range or volume bar charts?
Yes, it adds up the volume at each price from the underlying data. But profiles with a fixed time period start and end on bar boundaries, so on range, volume or Renko bars a profile can begin a little before or after the session start. Sierra Chart only expects an exact match between charts when both use time-based bars.
Why is my profile different after reloading the chart?
A reload can pull in more or less history, or rebuild from tick data that differs from what was previously stored. Check Days to Load and your data storage setting after any reload.
Is the Volume by Price study the same as a TPO profile?
No. Volume by Price measures traded volume at each price, while a TPO profile counts the time periods in which price traded there. They often agree on broad structure but can place the POC at different prices. The volume profile vs market profile comparison explains when each one helps.
How do I put a volume profile on every bar?
Set Volume Graph Period Type to Multiple Profiles Based on Bar Count and Number of Bars for 'Based On Bar Count' to 1. Use a narrow width so the profiles do not overlap the next bar.
Does Volume by Price use market depth data?
No. It is built from traded volume only. Resting orders in the book are shown by market depth views such as the heatmap, which need separate depth data.
