How to set up a footprint chart in Sierra Chart

To build a readable footprint in Sierra Chart, add the Numbers Bars study to a chart that uses Intraday Data with bid and ask volume recorded, choose the Bid x Ask Volume display, and set a price aggregation that keeps each bar to a manageable number of rows. Then simplify colors so that imbalances stand out and the rest recedes. The sections below cover each setting in order.

This guide is about configuration. If you need help interpreting the numbers once the chart works, see our guide on how to read a footprint chart.

Before you start: data requirements

A footprint needs trade-level data split into volume traded at the bid and at the ask. Check these items first:

• Your data feed must supply tick or bid/ask tagged data for the instrument, such as ES, NQ, CL or EURUSD. Many forex feeds provide tick volume only, so EURUSD footprints are not equivalent to exchange-traded futures volume. CME futures like ES, NQ and CL carry real traded volume.
• In Global Settings >> Data/Trade Service Settings, set Intraday Data Storage Time Unit to 1 tick so bid and ask volume is recorded. Sierra Chart documents this in its tick by tick data configuration page.
• Load enough history for your use. Footprints on historical data require that the data was downloaded with bid/ask volume, so check your service package.

Step 1: add the Numbers Bars study

1. Open your chart and choose Analysis, then Studies.
2. Find Numbers Bars Calculated Values and Numbers Bars in the list of available studies. Add the main Numbers Bars study to the chart.
3. Set the chart bar type to something that matches your purpose, for example a 5 minute, 500 volume or range bar chart. Footprints read best when each bar has enough trading to show a pattern.
4. Open the study settings to reach the Numbers Bars options.

Many traders keep a separate chart just for the footprint, and keep a regular candlestick chart for context.

Step 2: choose the bid ask volume display

In the Numbers Bars settings, look for the Numbers Bars Data Type or the display option for each cell. The common choices are:

• Bid Volume x Ask Volume: shows both sides at each price, left and right. This is the standard bid ask volume footprint.
• Total Volume: one number per price, good for spotting where volume clustered.
• Delta: ask minus bid at each price, useful when you want less clutter.

For a first footprint, use Bid x Ask. It exposes the raw numbers, and you can switch to delta later once you know what you are looking for.

Step 3: set price aggregation

Aggregation is the most common reason a footprint looks unreadable. Each row of the footprint covers a number of ticks. Too fine and the bar is a wall of tiny numbers, too coarse and you lose detail.

In the Numbers Bars settings, use the Volume at Price Multiplier or the price increment option to group ticks into rows. Starting points, to adjust by screen size and timeframe:

• ES: tick size is 0.25. A multiplier of 1 shows every tick, and 2 to 4 (0.50 to 1.00 point rows) often reads better on 5 minute bars.
• NQ: tick size is also 0.25, but the instrument moves in larger ranges. Multipliers of 4 or more are common to keep bars compact.
• CL: tick size is 0.01, and a move of a dollar is 100 ticks. Multipliers of 2 to 5 help a lot.
• EURUSD: pricing depends on your feed, and the pip fraction can be very fine. Aggregate to at least a pip per row and remember volume may be tick counts.

Check contract specifications on the CME Group site when you are unsure of tick sizes or values.

Step 4: make the text readable

Readability comes from font size, row height and number format.

• Set a font size that fits the row height. If numbers overlap, increase aggregation rather than shrinking the text.
• Widen bars using the chart bar spacing control, so each cell has room for two numbers.
• Use a number format that abbreviates large values if you trade NQ or high-volume bars.
• Turn off extra elements you do not need, such as bar outlines, while you learn the layout.

Step 5: choose colors and imbalance highlights

Color should answer one question per glance. A simple scheme works best:

• Use a dark or neutral background with gray or muted text for normal cells.
• Enable imbalance highlighting in Numbers Bars, which colors a cell when the ask volume exceeds the bid volume on the diagonal by a chosen ratio, such as 300 percent. Use one color for ask dominance and another for bid dominance, for example green and red, or blue and orange if you want color-blind friendly contrast.
• Color the point of control row or highest volume row with a border or light fill. For background on that concept, see what point of control means in volume profile.
• Avoid coloring every cell. If everything is highlighted, nothing stands out.

The ratio is a preference, not a rule. Lower ratios mark more cells, higher ratios mark fewer. Test a few on ES or NQ during a normal session and keep the one that leaves the chart legible.

Step 6: add summary rows and save a footprint chart template

Numbers Bars can show per bar totals such as volume, delta and cumulative delta beneath the bar. Add only the ones you will actually use, typically bar delta and total volume.

Once the layout works, save it so you do not rebuild it:

1. Use File, then Save Chartbook As, or apply the chart to a Chartbook you can reuse.
2. Use the study setting Save as Defaults if you want new Numbers Bars studies to start from these values.
3. For a footprint chart template per instrument, keep separate chart copies for ES, NQ, CL and EURUSD, since the aggregation differs for each.

If you want to compare setup styles and supporting tools such as DOM and volume profile, our overview of the best Sierra Chart tools for order flow may help.

A legible footprint color scheme

Step 5 decides which cells get highlighted. This section keeps the whole footprint readable over a full session: build the colors in layers, from the background up to the imbalance accents.

Layer 1: background and structure

Pick a background first, because every other color is judged against it. Dark charcoal or off-white both work. Pure black with saturated colors tends to cause glare during long sessions, and pure white makes pale cell colors disappear.

Then tone down the structure:

• Grid lines: very close to the background color, or off.
• Bar outlines: a mid gray, thin.
• Price scale and labels: a neutral gray rather than white or black.

The test: squint at the chart. If you can still see the grid clearly, it is too strong.

Layer 2: bid ask contrast

Bid ask contrast is the core of a footprint. Assign one hue family to bid volume (sellers hitting the bid) and another to ask volume (buyers lifting the offer). The classic choice is red for bid and green for ask, but it is not the only good one.

Roughly one in twelve men has some form of red-green color vision deficiency. Blue for ask and orange for bid reads well for most people and still feels intuitive. Whatever you pick, keep it consistent with your DOM and other order flow charts so you never have to translate colors between windows.

Keep the text color for ordinary cells neutral (light gray on dark, dark gray on light). Let the background or a subtle tint carry the bid ask side, not bright text. Bright colored text on a colored background is usually the first thing that makes a footprint unreadable.

Layer 3: volume intensity

Numbers Bars can scale background color with volume, so low-volume cells stay pale and high-volume cells get darker or more saturated. Look for inputs that set a high and a low color, or a gradient, and pick a narrow range. A pale tint to a medium tone is usually enough. If your highest volume color is as loud as your imbalance accent, the hierarchy collapses.

Check the scaling on a busy instrument and a quiet one. A gradient that looks balanced on ES during regular hours can leave almost every cell pale on a slow overnight session, or flatten everything on a high volume CL inventory release. If the study offers a choice between scaling within each bar and scaling across the visible chart, test both. Per bar scaling shows the structure inside each bar, while chart-wide scaling makes bars comparable to each other.

For what the underlying values mean, see the guide to Numbers Bars calculated values.

A starting palette to adapt

On a dark charcoal background, a scheme that works well as a baseline:

• Ordinary text: light gray.
• Ask side tint: desaturated blue, darker with volume.
• Bid side tint: desaturated orange, darker with volume.
• Ask imbalance: bright cyan text or outline.
• Bid imbalance: bright magenta text or outline.
• Bar POC: yellow outline.
• Grid: off, or one step lighter than the background.

Treat it as a starting point, not a standard. Your monitor, room lighting and eyes matter more than any preset.

Common setup problems

• Empty or zero cells: bid/ask volume was not recorded for that period. Reload data or check the feed.
• Numbers too crowded: raise aggregation or widen the bars.
• Delta looks wrong on forex: your feed may supply tick volume, which is not the same as traded volume.
• Slow chart: reduce the days loaded or simplify the study calculations.

For the complete list of options, see the Sierra Chart Numbers Bars documentation.

Conclusion

A good footprint setup is mostly restraint: record bid and ask data, pick the Bid x Ask display, aggregate until rows are legible, and use color sparingly for imbalances and the highest volume row. Save the result as a template for each instrument. A readable chart does not predict anything, it only makes the recorded order flow easier to study. Explore order flow tools, MT5 expert advisors and courses at SierraOnShop.

FAQ

Can I use a footprint chart on a range or volume bar chart?

Yes. Numbers Bars works with time, tick, volume and range bars. Volume and range bars give each bar a more even amount of activity, which can make cells easier to compare.

Why are my bid and ask numbers identical or missing?

Usually the data does not contain bid/ask tagged volume, or the chart is not recording it. Check the intraday data settings and your data feed's capabilities.

How many days of data should I load for a footprint?

Load only what you need for your analysis, often a few days. More history slows the chart and may not be available with bid and ask detail.

Does the same footprint setup work for futures and forex?

Not exactly. Futures such as ES and CL report real traded volume, while many spot forex feeds report tick volume. Adjust aggregation and treat forex results with that limit in mind.
