What a Sierra Chart TPO profile chart setup involves
To set up a TPO profile chart in Sierra Chart, set the session times in Chart >> Chart Settings, then add the TPO Profile Chart study from Analysis >> Studies and set its letter period (30 minutes by default) and its price increment per row. Most broken TPO charts come from a wrong session window or time zone, not from the study itself.
Below: the parts of a TPO chart, the settings, and fixes for common problems. If you are still deciding between time-based and volume-based profiles, read volume profile vs market profile for futures first.
Get professional chartbooks for Sierra Chart
DOM, footprint, heatmap and market profile setups, installed in seconds. Our trading courses cover the method behind them.
“Chartbooks are superb, I save a lot of time! Thanks for these quality products.”
The components of a TPO chart
A TPO (Time Price Opportunity) chart records which prices traded during each time period of a session. Each period gets a letter or a block. When price trades at a level during that period, the profile prints that letter at that row. Stack the periods side by side or collapse them into one column, and the session takes on a distribution shape.
Market profile letters and periods
With 30-minute periods, the first half hour of the session prints as A, the second as B, and so on. A regular ES session from 9:30 to 16:00 Eastern gives you 13 periods. Collapsed, the profile shows how many periods visited each price. Expanded, or split, it shows the order in which the auction developed.
When you read letters, look for three things:
- Where early letters sit compared with late letters, which shows the direction the session moved over time.
- Rows with only one letter (single prints), which show prices the market passed through quickly.
- Letters that print outside the initial balance, called range extension.
Initial balance
The initial balance is the range of the first two periods, A and B, so the first hour with 30-minute periods. Sierra Chart draws it as a vertical bar to the left of each profile. With the wrong session start, your initial balance covers the wrong hour, and every level built on it moves with it.
Point of control and value area
The TPO point of control is the price row with the most letters. The value area is the range around it that contains a set share of TPOs, conventionally 70 percent. Sierra Chart builds it outward from the POC, adding the side with more TPOs until it reaches that share. TPO and volume calculations can give a different POC for the same session, which is normal. For the volume-based version, see what point of control means in volume profile.
Open, close and tails
Most TPO displays can mark the session open and close inside the profile. Single-print tails at the session extremes are often read as rejection at those prices. These are observations about the auction, not trade signals.
Step 1: set the session periods in Chart Settings
The TPO study builds one profile per session using the chart's session times. Open the chart, go to Chart >> Chart Settings, and find the Session Times settings. The Sierra Chart Chart Settings documentation describes each field. Check:
- Time zone. Session times are entered relative to the time zone set in Sierra Chart (Global Settings >> Time Zone), not the exchange's. Confirm the zone before entering times.
- Session start and end. For a regular-hours profile on ES or NQ, use 09:30:00 to 15:59:59 Eastern, or 08:30:00 to 14:59:59 Central if your platform runs on Central time. The End Time includes its full last second, so 16:00:00 can add a stray bar. For CL, many profile traders use the old pit hours, 9:00 to 14:30 Eastern. For a full Globex profile, use the electronic session hours shown in the contract specifications on CME Group.
- Use Evening Session. Leave it unchecked for a day-session-only profile. For separate overnight and day profiles, see the section below.
EURUSD spot has no central exchange session, so there is no standard regular-hours window. Pick a definition you can apply consistently, such as a full 24-hour day or a London plus New York window. Write it down so your profiles are comparable from day to day.
After saving, scroll back a few sessions. The first letter should start at your session open, and each day should begin a new profile. If the profiles start an hour early or late, the problem is almost always the time zone.
Step 2: check tick size and loaded data
You do not pick a bar period for a TPO chart. On intraday charts, Sierra Chart sets the underlying bars to 1 minute when the TPO study is applied, and that cannot be changed. Instead, check these in Chart >> Chart Settings:
- Tick Size. A wrong tick size makes profiles display incorrectly or load slowly. Confirm it matches the contract, for example 0.25 for ES.
- Days to Load. TPO profiles do not need tick by tick data the way footprint charts do, but you need enough history to cover the sessions you want. If older profiles are missing, raise this value.
The Sierra Chart chartbook data requirements guide explains which views need which data.
Step 3: add and configure the TPO Profile Chart study
Go to Analysis >> Studies, select TPO Profile Chart in the Studies Available list, press Add, then Settings. Your Service Package must include this study. The TPO Profile Chart documentation describes every input. These are the ones to set first:
| Input | What it controls | Starting value |
|---|---|---|
| TPO Letter/Block Time Period Length | Minutes per letter | 30 |
| Profile Time Period Length and Length Unit | How long each profile lasts | 1 and Days |
| Letter/Block Price Increment in Ticks | Ticks per row (0 = automatic) | See below |
| Sub Period Price Display Style | Letters, Blocks or Horizontal Bars | Letters while learning |
| Letters Always Start at Primary Session Start Time | Letter A begins at the session Start Time | Yes |
| TPO Value Area % | Share of TPOs in the value area | 70 |
| Initial Balance Range | Number of letter periods in the IB | 2 (one hour with 30-minute letters) |
Turn on only the markers you will use: Highlight TPO POC, Highlight TPO Value Area, Highlight Open in Profile and Highlight Close in Profile. Letters let you read period order. Blocks are cleaner when you only care about shape and value area.
To split a profile into one column per period, right-click it and choose Letters/Blocks In Own Column. Default Column Display Style (For All Profiles) applies a style to every profile.
Tick size and row size
Each profile row equals the number of ticks set in Letter/Block Price Increment in Ticks. ES and NQ have a 0.25 tick, YM a 1-point tick, RTY 0.10 and CL 0.01. On ES with one tick per row, a 40-point session gives 160 rows. Combining rows, for example four ticks per row on ES or ten ticks on CL, keeps the shape readable. The trade-off: prices are rounded to the row, so the profile high, low, POC and value area become less precise. Sierra Chart recommends an increment of 1 when you need exact high and low values. Choose one row size per instrument and keep it fixed so profiles from different days compare cleanly. The volume by price study setup guide covers the same row size reasoning for volume profiles.
Separate day and evening session profiles
With the evening session enabled, a 1-day TPO profile normally starts at the evening open and runs through the day session. To get separate overnight and day profiles:
- In Chart >> Chart Settings, enable Use Evening Session and set the Evening Start and Evening End times. Keep Start Time and End Time on the day session.
- In the TPO Profile Chart study, keep Profile Time Period Length at 1 and Length Unit at Days.
- Set New Period at Day Session Start When Using Evening Session (1 Day Period Only) to Yes.
- Optional: set TPO Letter/Block Colors to Separate Colors for Day and Evening Sessions.
To keep only today's overnight profile, set Exclude Evening Session Profiles Except For Last Day to Yes, then use Chart >> Recalculate to clear older ones.
Step 4: validate the profile
Before relying on the chart, run these checks:
- The first letter of each session lines up with your intended open time.
- The count of periods matches the session length, for example 13 for a 9:30 to 16:00 session with 30-minute letters.
- The session high and low on the profile match the high and low of the underlying bars for that window.
- The initial balance covers the first hour, not the first hour of the overnight session.
- The current day's profile keeps updating as new bars arrive.
If you trade both overnight and regular hours, compare the same day with both session definitions. Seeing how much the POC and value area move is a good lesson in why session choice matters.
Troubleshooting common TPO chart problems
- Letters overlap or are only partly visible. Increase Letter/Block Price Increment in Ticks, expand the price scale, or set Letter Font Size to 0 (automatic). If letters come out thin and far apart instead, set a fixed font size, then adjust bar spacing.
- A single row of letters, or hundreds of tiny rows. The price increment does not fit the tick size. Check Tick Size in Chart Settings, then the increment.
- Letters are missing for part of the session. Use Chart >> Duplicate Chart, remove the TPO study from the copy, and scroll the 1-minute bars across your session window. Gaps there are data gaps, not a study setting.
- Odd first period when the session starts off the half hour. Change 30 Minute Letter/Block SubPeriod Handling to merge the short period or restart on even 30-minute blocks.
- Two TPO charts disagree. Compare the time zone, the session times and every study input. The session times must match exactly.
Save your work
Once the profile reads correctly, save the chart inside a chartbook (.Cht) so the session times and study settings come back together. If you want to reuse only the study configuration on other charts, save it as a study collection (.stdycllct). The Sierra Chart chartbook documentation explains what each file keeps.
If you would rather start from a working layout, a Sierra Chart market profile chartbook with TPO, value area, POC and volume profile already configured lets you skip the setup and spend the time checking the session times against your own trading hours.
Conclusion
A reliable TPO chart in Sierra Chart comes down to the order of operations: time zone and session times first, a correct tick size, then the TPO study with a consistent row size per instrument. Learn the letters, initial balance, POC, value area and single prints on a split display, then collapse it once the shapes mean something to you. To skip the configuration, SierraOnShop offers ready-to-use Sierra Chart chartbooks, including a market profile layout.
FAQ
Why does my TPO profile start at midnight instead of the market open?
The chart is using a session that starts at midnight or the time zone is different from the one you entered times in. Check Global Settings >> Time Zone and the session Start Time in Chart Settings, then reload the chart.
Can I show overnight and day profiles on the same chart?
Yes. Enable Use Evening Session in Chart Settings and set New Period at Day Session Start When Using Evening Session (1 Day Period Only) to Yes in the TPO study. Each date then shows a separate evening profile and day profile.
Should I use letters or blocks?
Letters are better while you learn, because they show when each price traded. Blocks are easier to scan once you mainly read shape, value area and POC.
Do I need market depth data for a TPO chart?
No. TPO profiles are built from traded prices over time. Market depth data is only required for DOM, depth and heatmap views.
Is a 30-minute letter period required?
No, it is a convention and the study default. Shorter periods such as 15 minutes give more detail on fast instruments like NQ, but your initial balance and period counts change, so keep the setting consistent across days.
How do I add a volume profile to a TPO chart?
Add the Volume by Price study to the same chart. It follows the TPO profile periods automatically. Set Align Volume Profiles To TPO Profiles to Yes in the TPO study to draw it over the TPO profile.
Can I add other indicators to a Sierra Chart TPO chart?
Only a few. Sierra Chart supports Volume by Price, Countdown Timer, Current Price Line and, in some cases, Study/Price Overlay on a TPO Profile Chart. For moving averages, VWAP or delta, use a second chart with the same symbol and session times.
