Sierra Chart DOM setup for futures: Trade DOM columns, depth data and a readable layout

What a usable Sierra Chart DOM setup for futures needs

A usable Sierra Chart DOM setup for futures comes down to three layers: market depth data that actually reaches the platform, a Trade DOM whose price ladder matches the contract's tick size, and a small set of market depth columns arranged so you can read them at a glance. If any of those three is wrong, the ladder looks empty, jumps around or shows numbers you cannot trust. This guide covers the display and data settings in that order. It does not cover when to trade.

The Trade DOM is Sierra Chart's vertical price ladder. It is technically a chart window displayed as a ladder, which is why many of its options live in Chart Settings rather than in a separate DOM menu. Keep that in mind when you look for a setting.

Step 1: confirm market depth data is flowing

A DOM is only as good as the depth feed behind it. Before you touch any column, check the data side.

1. Data feed subscription. Your data service must provide market depth for the exchange you trade. For ES, NQ, YM and RTY that means CME depth, and for CL it means NYMEX depth. Top of book alone gives you one bid and one ask, not a ladder.
2. Market depth enabled in Sierra Chart. Open Global Settings >> Data/Trade Service Settings and confirm that market depth is not disabled for your service. The exact option name can vary by version and data service, so read the labels on that window rather than relying on memory.
3. Depth levels. The number of visible levels is limited by your feed, and Sierra Chart also has a setting for how many depth levels to request or display. Check Chart Settings for a market depth levels option and compare it with what your feed delivers.

A quick test: open the DOM on the front-month ES contract during regular trading hours. You should see size at many price levels above and below the inside market. If you only see the best bid and ask, the issue is data, not layout.

For spot EURUSD, be aware that there is no single centralized order book. Any depth you see comes from your specific provider. Traders who want exchange depth on the euro often watch the CME Euro FX futures contract instead.

Step 2: get tick by tick data for volume columns

Market depth columns show resting orders. Volume columns, such as recent bid volume, recent ask volume or volume at price, are built from trades. Those are more reliable when the chart stores tick by tick data.

In Global Settings >> Data/Trade Service Settings, set Intraday Data Storage Time Unit to 1 tick. Sierra Chart documents the full process, including how to reload data after the change, in its tick by tick data configuration guide. This is the same setting a footprint needs, so if you already followed our Sierra Chart footprint chart setup you are probably covered.

Step 3: open the Trade DOM and match the symbol

Open a Trade DOM for your symbol from the Trade menu or from the symbol search window, depending on your version. Then verify:

• Correct contract. Futures symbols in Sierra Chart include the contract month and exchange suffix in the format your data service uses. A DOM opened on an expired or wrong-month symbol will show no depth.
• Tick size. The ladder should step in the contract's minimum tick. ES and NQ move in 0.25, YM in 1, RTY in 0.10 and CL in 0.01. If your ES ladder steps in 1.00, check the tick size and price display settings in Chart Settings.
• Price format. CL prints two decimals, ES and NQ two decimals in quarter steps. A wrong display format makes the ladder hard to read even when the data is correct.

The Chart Settings documentation lists the options that apply to chart windows, which includes the Trade DOM.

Step 4: choose your market depth columns

This is where most DOMs become cluttered. Sierra Chart offers many columns, and adding all of them makes the ladder slower to read. Open the DOM column customization option from the Trade menu (the label refers to customizing Trade or Chart DOM columns), then add, remove and reorder columns.

A practical starting set, from left to right:

Optional columns to consider after the basics work:

• Pulling and stacking. Shows changes in resting depth at each level. Useful for order book reading, but noisy on fast contracts like NQ.
• Last trade size. Shows the latest print beside the price.
• Profit and loss or position columns. Helpful if you trade from the DOM, but they add width.

Check exact column names in your version's list rather than searching for names from other platforms. If a column shows nothing, it usually needs data you have not enabled, either depth or tick by tick.

Step 5: build a readable DOM layout

Once the columns are right, tune the display.

• Row height and font. Rows should be tall enough to read sizes without squinting, but short enough to show a useful range. On ES, around 30 to 40 visible rows above and below the inside market is a reasonable range for a single monitor. Adjust font and row size in the chart's display settings.
• Centering behavior. Decide whether the ladder should recenter on the last price automatically or stay fixed until you recenter it. Automatic recentering is easier on CL during spikes; a fixed ladder is calmer to read on slower sessions. Look for the recentering option in Chart Settings and test both.
• Color contrast. Use one color family for bids and another for asks, with neutral backgrounds. Avoid bright highlights on every column, or nothing stands out.
• Large size highlighting. If your version supports highlighting depth above a threshold, set the threshold per instrument. A size that is notable on RTY may be ordinary on ES.
• Column width. Narrow price and order entry columns, wider size columns. Sizes on ES can reach several hundred contracts, so leave room for three or four digits.

Pair the DOM with one context chart rather than several. If you want to weigh the DOM against footprint and profile tools, our comparison of the best Sierra Chart tools for order flow covers what each one shows.

Step 6: save the layout so you do not rebuild it

Save the DOM inside a chartbook (.Cht) so the window, columns and settings reopen together. Sierra Chart explains how chartbooks store windows in its chartbook documentation. When the contract rolls, change the symbol in the saved DOM rather than building a new one.

If you would rather start from a working ladder and adjust it, a configured Sierra Chart depth of market chartbook gives you a DOM and order book workspace you can open and then adapt to your contract and screen.

Troubleshooting quick checks

• Empty ladder: wrong contract month, no depth subscription or depth disabled in Data/Trade Service Settings.
• Only bid and ask shown: depth levels limited by the feed or by the depth levels setting.
• Volume columns blank or odd: storage time unit is not 1 tick, or data needs reloading.
• Saved DOM opens blank after loading: see our guide on a Sierra Chart chartbook not displaying correctly.

Conclusion

A Sierra Chart Trade DOM becomes usable once depth data is confirmed, tick by tick storage feeds the volume columns, the ladder matches the contract's tick size and the columns are limited to what you will actually read. Build it on one instrument, such as ES, save it in a chartbook, then copy it to NQ, CL or RTY and adjust thresholds and row ranges. If you prefer a configured starting point, browse the Sierra Chart chartbooks at SierraOnShop.

FAQ

Can I run more than one Trade DOM at once?

Yes. Each Trade DOM is its own window, so you can open one for ES and one for NQ. Each one draws on your depth data, so check that your feed and computer handle several active ladders smoothly.

Why does my DOM work on ES but not on CL?

The most common cause is that your depth subscription covers CME but not NYMEX, or that the CL symbol uses the wrong contract month. Check both before changing layout settings.

Does the DOM show historical depth?

The standard ladder shows current depth. Viewing how resting orders changed over time needs a depth recording and a heatmap style display, which is a separate setup.

Should I use the same column set for scalping and for monitoring?

Not necessarily. A monitoring DOM can drop order entry columns entirely, which frees width for depth and volume columns. Save each version as a separate chartbook.
